Drilling
Ø13
Tapping
M10
Loading
ATC
TECHNICAL FEATURES
| Type | T20-SK40 | Code | 124936.100 |
| Type | T20-BT40 | Code | 124937.100 |
| Type | T20-CAT40 | Code | 124986.100 |
| Type | T20-HSK63 | Code | 124951.100 |
| Tool-holder for collet | ER 20 |
| Input shank rotation | SX / LH |
| Output spindle rotation | DX / RH |
| Transmission ratio | 1:1 |
| Max speed | 12000 rpm |
| Torque | 10 Nm |
| Max axial load | 350 N |
| Weight | 5 Kg |
| Grease lubricated | Klüber Isoflex NBU 15 |
OPTIONS
STANDARD EQUIPMENT
| ER20 collet DIN 6499/B | 411220.100 |
| Tapping collet ET-1-20 with compensation | 401220.200 |
| Tapping collet ER20 with square | 411220.200 |
| Weldon spindle type | |
| ABS license Komet spindle type | |
| Pin pitch 80 mm |
| Standard stop-block | 311201.025 |
| ER nut | |
| Clamping wrench | |
| Grease tube | |
| Storage case |
