Drilling
Ø16
Tapping
M12
Loading
ATC
TECHNICAL FEATURES
| Type | T25-SK40 | Code | 124961.100 |
| Type | T25-BT40 | Code | 124962.100 |
| Type | T25-CAT40 | Code | 124963.100 |
| Type | T25-HSK63 | Code | 124964.100 |
| Tool-holder for collet | ER 25 |
| Input shank rotation | SX / LH |
| Output spindle rotation | DX / RH |
| Transmission ratio | 1:1 |
| Max speed | 6000 rpm |
| Torque | 13 Nm |
| Max axial load | 500 N |
| Weight | 5 Kg |
| Grease lubricated | Klüber Isoflex NBU 15 |
OPTIONS
STANDARD EQUIPMENT
| ER25 collet DIN 6499/B | 411225.100 |
| Tapping collet ET-1-25 with compensation | 401225.200 |
| Tapping collet ER25 with square | 411225.200 |
| Weldon spindle type | |
| ABS license Komet spindle type | |
| DIN 69893-HSK spindle type | |
| Pin pitch 110 mm |
| Standard stop-block | 311201.025 |
| ER nut | |
| Clamping wrench | |
| Grease tube | |
| Storage case |
