Drilling
Ø3
Tapping
M3
Loading
ATC
TECHNICAL FEATURES
| Type | A5-SK50-S243 | Code | 124409.100-S243 |
| Type | A5-BT50-S257 | Code | 124410.100-S257 |
| Type | A5-CAT50-S243 | Code | 124411.100-S243 |
| Type | A5-HSK100-S253 | Code | 124412.100-S253 |
| Tool-holder for collet | 6023E |
| Input shank rotation | SX / LH |
| Output spindle rotation | DX / RH |
| Transmission ratio | 1:1.1 |
| Max speed | 8000 rpm |
| Weight | 10.5 Kg |
| Grease lubricated | Kluber Isoflex NBU 15 |
OPTIONS
STANDARD EQUIPMENT
| 6023E collet | |
| Pin pitch 110 mm |
| Standard stop-block | 311201.025 |
| Grease tube | |
| Storage case |
