Drilling
Ø10
Tapping
M8
Flange mounted
MTC
TECHNICAL FEATURES
| Type | 805 | Code | 111805.100 |
| Tool-holder for collet | ER 16 |
| Transmission ratio | 1:1 |
| Max speed | 3000 rpm |
| Spindle max power | 0.56 Kw |
| Max axial load | 753 N |
| Weight | 6.6 Kg |
| Grease lubricated |
OPTIONS
| ER16 collet DIN 6499/B | 411216.100 |
| Quill clamp | 410106.000 |
| Driver | |
| Joint | |
| Clamping wrench | 410216.000 |
