Drilling
Ø16
Tapping
M12
Flange mounted
MTC
TECHNICAL FEATURES
| Type | 115 | Code | 111215.100 |
| Mandrino | DIN 55058 Ø 16 |
| Transmission ratio | 1:1 |
| Max speed | 2500 rpm |
| Spindle max power | 1.1 Kw |
| Max axial load | 1135 N |
| Weight | 6.3 Kg |
| Grease lubricated |
OPTIONS
| Quill clamp | 410107.000 |
| Driver | |
| Joint |
