Drilling
Ø16
Tapping
M12
Flange mounted
MTC
TECHNICAL FEATURES
| Type | 127P | Code | 111909.100 |
| Tool-holder for collet | ER 25 |
| Transmission ratio | 1:1 |
| Max speed | 3000 rpm |
| Torque | 28 Nm |
| Max axial load | 2390 N |
| Weight | 16.5 Kg |
| Grease lubricated |
OPTIONS
STANDARD EQUIPMENT
| ER25 collet DIN 6499/B | 411225.100 |
| Tapping collet ET-1-25 with compensation | 401225.200 |
| Tapping collet ER25 with square | 411225.200 |
| Quill clamp | |
| Driver | |
| Joint |
| Chiavi |
