Clamping
Ø16
Flange mounted
MTC
TECHNICAL FEATURES
| Type | 901 | Code | 131901.100 |
| Tool-holder for collet | ER 25 |
| Main drive rotation | DX / RH |
| Output spindle rotation | DX-SX / RH-LH |
| Transmission ratio | 1:1 |
| Max speed | 2000 rpm |
| Spindle max torque | 16 Nm |
| Max axial load | 1500 N |
| Weight | 13.7 Kg |
| Grease lubricated | Klüber Isoflex NBU 15 |
OPTIONS
| ER25 collet DIN 6499/B | 411225.100 |
| Quill clamp | 410125.000 |
| Driver | |
| Joint | |
| Clamping wrench | 410325.000 |
