Drilling
Ø20
Tapping
M16
Loading
ATC
TECHNICAL FEATURES
| Type | A-ISO30-SK40 | Code | 124705.100 |
| Type | A-ISO30-BT40 | Code | 124706.100 |
| Type | A-ISO30-CAT40 | Code | 124707.100 |
| Type | A-ISO30-HSK63 | Code | 124708.100 |
| Spindle tool-holder | DIN 2079-30 |
| Input shank rotation | SX / LH |
| Output spindle rotation | DX / RH |
| Transmission ratio | 1:1 |
| Max speed | 3500 rpm |
| Torque | 40 Nm |
| Max axial load | 750 N |
| Weight | 7.4 Kg |
| Grease lubricated | Kluber Isoflex NBU 15 |
OPTIONS
STANDARD EQUIPMENT
| Weldon spindle type | |
| Mill arbor | |
| Pin pitch 80 mm |
| Standard stop-block | 311201.025 |
| Grease tube | |
| Storage case |
